FCLRPD0005
CLRP Polyamide washable cartridge
The CLRP polyamide washable cartridge is designed to protect boilers, washing machines, to filter sand, scale, rust.
Versatile industrial use includes protecting water pumps, irrigation, gardening and car wash services.
TDS CLRP Polyamide washable cartridge
Size
2.5" × 10"
Flow rate
1 100
L/h
Maximum working temperature
4 - 45
°C
Filtration rating
50
micron
Technical specifications
- Model - CLRP
- Filtration - Sediments
- Filtering medium - Polyamide
- Inter core - Polypropylene
- Valves - Polypropylene
- Gasket - Elastomer
- Connection - DOE
- Working temperature - From 4°C (39°F) to 45°C (113°F)
- Cartridge type - Washable
- Maintenance - Quarterly
- Duration - 24 months
- Size - 5"
- Flow rate, l/h - 1 100
- Filtration rating, µ - 50
CLRP POLYAMIDE WASHABLE CARTRIDGES IN OTHER SIZES
FCLRPD0010: Size - 5"
Flow rate, l/h - 1 100
Filtration rating, µ - 250
FCLRPD0015: Size - 7"
Flow rate, l/h - 1 500
Filtration rating, µ - 50
FCLRPD0020: Size - 7"
Flow rate, l/h - 1 500
Filtration rating, µ - 250
FCLRPD0025: Size - 9" ¾
Flow rate, l/h - 2 200
Filtration rating, µ - 50
FCLRPD0030: Size - 9" ¾
Flow rate, l/h - 2 200
Filtration rating, µ - 250
Product
Image Size
DIMENSIONS, H×W×D:
127 x 70 x 28
mm
Filter weight
kg
